FUSION 600E
HARDFACING WELD ELECTRODE FOR CARBON AND LOW ALLOY STEELS
FUSION™ 600E
FUSION™ 600 E, a hardfacing electrode, is an excellent option for carbon and low alloy steels, cast iron and manganese, bonding readily to all. It is intended for applications with impact and abrasion resistant qualities, being the optimum choice to the combination. The deposits take a high polish, contributing the wear qualities, and applies well out of position.
FUSION™ 600 E, a hardfacing electrode, is an excellent option for carbon and low alloy steels, cast iron and manganese, bonding readily to all. Primary applications for FUSION™ 600 E involve severe abrasion with moderate to heavy impact. It is normally used for earth-to-metal wear or wear due to abrasion of other particulate material. FUSION™ 600 E is a solid cored electrode with a heavy extruded coating which contains the alloying elements. It can be applied out of position. Deposits are uniform with excellent bead appearance and slag removal. It develops surface checks and is not machinable or forgeable. Compressive strength is very high.
Common applications include:
- Bucket Teeth
- Crusher Rolls
- Edges
- Hammers
- Jaw Crushers
- Mill Hammers
Typical Deposit Characteristics
| Abrasion Resistance | Excellent |
| Impact Resistance | Moderate |
| Comprehensive Strength | Very High |
| Hardness | HRC 57 – 61 |
| Hot Hardness Temperature | Up to 1,000°F |
| Magnetic | |
| on Carbon Steel on Manganese Steel |
No No |
| Surface Cross Checks | Yes |
| Machinability | No |
| Deposit Layers | Up to 3 |
Operational Characteristics / Welding Parameters
| Diameter | 5/32” (4.0mm) OR 1/8” (3.2mm) |
| Current, Amp DCEP | 140 – 170 OR 90 - 120 |
| Postion | All |
| Length | 14" |
Alloy Type
Primary Chromium Carbides in an Austenitic Matrix
Typical Applications
- Bucket Teeth
- Crusher Rolls
- Edges
- Hammers
- Jaw Crushers
- Mill Hammers
Standard Sizes & Packaging
Diameter: 5/32” (4.0mm) OR 1/8” (3.2mm)
Packaging: 10 lbs. Vac Pack
DOWNLOAD THE SPECS
DO YOU NEED A PRINT OUT OF THE ABOVE INFORMATION?
We’ve made printing and presenting our information easy for you. Just download our Fusion 600 E Weld Wire & Rod Specification Document (PDF). If you need additional information, please contact us today!
