Extreme Abrasion Resistant Chromium Carbide Overlay Plate

Chromeweld Ti

CHROMEWELD™ Ti IS SPECIALLY BLENDED TO COMBAT IMPACT & ABRASION

CHROMEWELD Ti is a unique material that is ideal for surfaces requiring high levels of abrasion resistance, along with heavy impact. It is a premium grade of overlay wear plate developed with an ultra-tough matrix and finely dispersed abrasion and impact resistant, titanium carbides.

Incredible hardness, unrivaled performance

CHROMEWELD Ti typical hardness ranges from 56 - 60 HRC and will remain abrasion resistant at temperatures up to 1200 degrees F.

CHROMEWELD Ti plate surface exhibits fissures which are typical stress relieving characteristics essential to the abrasion and impact performance, enabling the plate to be formed, bent and rolled without damage.

CHROMEWELD Ti Fabrication Facts

Cutting: Plasma burning, air arc, abrasive saw cutting, or waterjet.
Machining: The overlay surface can be finished by grinding only. EDM, plasma arc cutting, or carbon-arc gouging may produce countersunk holes for bolts. Pre-machined mild steel inserts may be welded into straight holes for additional machining. CHROMEWELD Ti cannot be machined by ordinary methods.
Cold Bending: When using a press brake, forming should be perpendicular to the weld pass direction. Plate rolling should be performed in the direction of the overlay beads. Forming CHROMEWELD Ti to the outside will cause crosscheck cracks to open. This may require post-fabrication weld repair using suitable weld rod/wire.

Welding: CHROMEWELD Ti overlay plate can be joined by welding substrate to substrate using 309 weld wire/rod. Liner plates can be plug welded in place by welding the substrate to the base plate. Stud welds can be applied, but it is highly recommended that stainless steel studs be used. All weld seams; plug-weld holes, bolt holes, and all other joints exposed to wear should be protected by a cap weld of CHROMEWELD FUSION.

Mechanical Information

CHROMEWELD Ti typical hardness ranges from 56-60 HRC based on weld deposit thickness. The surface of the plate is a composite of titanium carbides in a high chromium martensitic matrix. The surface of the plate exhibits numerous hairline cracks which are a natural stress relieving phenomenon that is essential to the performance of the plate and enable it to be formed, bent, and rolled without damage.

General Overlay Chemistry

Your specific application needs, including custom requirements (thickness, alloy and size), are capable at JADCO. The JADCO process produces a microstructure consisting of fully martensitic matrix filled with primary carbides. This structure provides outstanding abrasion resistance in the most challenging applications.

Typical Chemistry Percent

2 Layer Deposit

Microscopic View

CW600 Microscopic
HOW TO WELD CHROMEWELD 600 VIDEO
Play Video

DOWNLOAD THE SPEC SHEET

REVIEW & DOWNLOAD OUR INFORMATIONAL CHROMEWELD Ti SPEC SHEET.
